Most of the work on this one is the part nobody sees. We fixed airtight boards to the ceiling rafters and taped them, sealed the junctions at the floor joists, brushed a liquid membrane where tape could not reach, and fitted grommets around every drainage pipe.
The sockets sit on structural insulation board, so they could be fixed securely without punching through the insulation line. Then the walls: battens first, then Diathonite lime-cork insulating plaster sprayed on in layers and levelled off by hand. We also blocked up an unused window in matching brick and built a new suspended floor while the house was open.
Preparation works for internal wall insulation in Muswell Hill, London
Blocking an unused window with matching bricks
New structural timber beams being installed
New suspended floor structure being installed
New suspended floor structure being installed
Phonotherm Structural insulation board installed behind, sockets
Phonotherm Structural insulation board installed behind sockets in Muswell Hill, London
Socket boxes installed onto Phonotherm structural insulation boards
Finsa SuperPan Airtight vapour barrier racking boards installed onto ceiling rafters
Finsa SuperPan Airtight vapour barrier boards taped around with ProClima airtightness tape
Finsa Airtight vapour barrier racking boards taped with ProClima airtightness tape in Muswell Hill, LOndon
Airtightness taping around floor joists at wall-floor junctions
Airtightness taping around floor joists - making junctions airtight in Muswell Hill, London
Airtightness work around floor joists using Aerosana Visconn fibre airtight liquid membrane in Muswell Hill, London
Airtightness works using Pro Clima Roflex Solido Airtight Grommet around drainage outlet in Muswell Hill, London
Battens are being installed in preparation for internal wall insulation
Battens are being installed in preparation for internal wall insulation
Battens are being installed in preparation for internal wall insulation
Battens ready for internal wall insulation
Diathonite Evolution lime-cork-clay insulating plaster-render spray machine
Diathonite Evolution lime-cork-clay insulation plaster being applied with spray pump onto solid masonry walls as internal wall insulation
Spraying Diathonite Evolution lime-cork-clay insulation plaster onto solid walls
Spraying Diathonite Evolution lime-cork-clay insulation plaster onto masonry walls
Diathonite Evolution lime cork insulation plaster sprayed in layers to reach required thickness in Muswell Hill, London
Diathonite Evolution lime cork insulation plaster being levelled off
Diathonite Evolution lime-cork-clay insulation plaster being levelled off
Diathonite Evolution lime-cork-clay insulation plaster being levelled off
Completed internal wall insulation with Diathonite Evolution lime-cork-clay system
Completed internal wall insulation with Diathonite Evolution lime-cork-clay system
